Description
The city is yours. Comfortable, stylish, and environmentally friendly. With the Image 3.B Advance, you're perfectly equipped for your tours both inside and outside the city. A practical luggage rack is included, as are lightweight mudguards for those wet days in the saddle. And the fully integrated Bosch motor provides momentum even when the headwind is particularly strong. The perfect e-bike for rediscovering your city in the future.
Refurbished: All our used bikes are fully serviced by our mechanics in the specialist workshop.
We give eBikes a second life. This means affordable and sustainable riding fun for you!
More Details
General Information
General Information
| Color: | white |
| Size: | L |
| Mileage: | 3324 km |
| Scope of Delivery: | including charger and instruction manual |
| Brand: | Kalkhoff |
| Model: | IMAGE 3.B ADVANCE Withdrawal |
| Model Year: | 2022 |
| Bike Status: | Refurbished |
Technical Details
Technical Details
| Maximum Speed: | 25 km/h |
| Wheel Size: | 28 inches |
| Bike Weight: | 26 kg |
| Frame Size: | 53 |
| Range: | 140 km |
| Walk Assist Mode: | Yes |
| Maximum Authorized Weight: | 130 kg |
Equipment and Components
Equipment and Components
| Battery: | 500 Wh |
| Battery Charger: | Original Bosch charger |
| Brakes: | Shimano MT200, 2-piston, hydraulic disc brakes |
| Brake Disc: | 180 mm | 160 mm |
| Display: | Intuvia (BES 2) |
| Rims: | Aluminum, hollow chamber with eyelets |
| Fork: | SR Suntour NEX E25 HLO |
| Fork Travel: | 63 mm |
| Luggage Rack: | Racktime Snap-It |
| Chain: | KMC Z1 EPT |
| Crank: | aluminum |
| Handlebar: | Tour, aluminum |
| Rear Light: | Herrmans H-Trace, LED |
| Front Light: | Herrmans H-Black MR4, LED |
| Engine: | Bosch Performance Line / 65 Nm |
| Frame: | Wave - Integrals 0.1 |
| Frame Material: | aluminum |
| Tires: | Schwalbe Energizer Active Plus, 50-622 |
| Saddle: | Selle Royal Essenza Plus |
| Shifter: | Shimano Nexus |
| Gear Speeds: | 5 courses |
| Gear Ratio: | 38 | 27 |
| Rear Derailleur: | 5-speed Shimano Nexus |
| Lock: | frame lock |
| Mudguards: | Plastic with edge protection |
Equipment may vary depending on the availability of spare parts.
Frame Sizes
The frame sizes listed in the table are recommendations based on body height. Please note that the optimal frame size also depends on individual factors such as your body proportions and personal preferences.
| City Bikes | Trekking Bikes | MTBs | |
| S | 155–166 cm | 155–166 cm | 155–169 cm |
| M | 164–180 cm | 164–180 cm | 167–180 cm |
| L | 178–191 cm | 178–191 cm | 175–190 cm |
| XL | 186–200 cm | 186–200 cm | 186–200 cm |
